| ブランド名: | HUAAO |
| モデル番号: | HE201 |
| MOQ: | 10 |
| 価格: | US$64.7-73.03/㎡ |
| パッケージの詳細: | 1。フォーム保護2。木製フレームのサポート3。フォークリフトの荷重とアンロード4。コンテナの荷重 |
| 支払条件: | L/C、T/T、D/A、D/P、T/T |
Huaao Cleanroom Doors
Description:
Huaao Cleanroom Doors: Role and Key Characteristics
Cleanroom doors are not merely access points; they are critical sealing components in a controlled environment. Their primary role is to maintain the integrity of the cleanroom enclosure by preventing the ingress of contaminants, facilitating safe personnel and material flow, and helping to sustain stable environmental conditions such as pressure differentials and temperature.
The effectiveness of a cleanroom door hinges on several specialized characteristics:
Airtight Sealing: Equipped with high-quality perimeter gaskets (often silicone or EPDM), these doors create a hermetic seal when closed to prevent air leakage, which is vital for maintaining ISO class standards and pressure cascades.
Smooth, Non-Shedding Surfaces: Doors are constructed from materials like stainless steel or powder-coated aluminum with seamless, cleanable finishes. This prevents particle generation and allows for easy decontamination.
Integrated Safety & Functionality: Features include safety vision panels, interlocking systems (to prevent simultaneous opening of adjacent doors), and automated operation to minimize touchpoints and air disturbance.
Durability & Compliance: Designed for high-frequency use in demanding environments, they are robust and often carry relevant fire ratings and certifications to meet industry-specific regulations (e.g., GMP, FDA).
In essence, Huaao cleanroom doors act as intelligent barriers, balancing secure access with uncompromising protection of the sterile internal environment.
Parameters:
| Type | Cleanroom swing door | Accessories | Door lack & Hingle & Door stopper |
| Model | HE201 | Color | Sky blue |
| Name | Single Opening Steel Door | Wall thickness | 75mm |
| Door frame steel plate thickness | 1.5mm | Door panel sheet material | Galvanized steel |
| Door panel steel plate thickness | 0.8mm | Filling | Aluminium honeycomb |
| Door panel thickness | 50mm | Window size | 400*600mm Circle |
| Seal | Door panel with sealing rubber strip Automatic lift dust seal under door | Place of use | laboratories, pharmaceutical factories, electronics factories, food factories |
Product advantage:
1. Air tightness: They help maintain a controlled and clean environment by preventing the leakage of air and contaminants.
2. Hygiene: Their smooth and non-porous surfaces are easy to clean and disinfect, reducing the risk of bacterial growth and contamination.
3. Durability: Steel construction ensures long-term use and resistance to wear and tear in a demanding cleanroom setting.
4. Resistance to chemicals: Can withstand exposure to various cleaning agents and chemicals commonly used in cleanroom operations.
5. Fire resistance: Provide an added level of safety in case of fire incidents.
6. Sound insulation: Minimize noise transmission, creating a quieter and more focused working environment.
7. Security: Offer enhanced protection for valuable equipment, materials, and processes within the cleanroom.
8. Aesthetic appeal: Present a sleek and professional look that contributes to the overall appearance of the cleanroom facility.
Applications:
Widely used in Hospitals, laboratories, pharmaceutical factories, electronics factories, new energy, aerospace, food factories, beverage factories, cosmetics and other purification fields.
Notices:
Colors:
Projcet Photos:
Our Clients:
FAQS:
Q1. Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3 days for Sample preparing ,8-10 working days for mass production.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 7-15 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order?
A: Firstly let us know your detail requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the quotaion and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
|
